PLC controlled servo motor for winding and arrangement device
Enlarged motor power and winding disc
Optimized linear arrangement device for better pipe arrangement.
mechanical wing of winder of reliable working
Suitabel for pipe 16-63mm
Torque motor for low speed and constant winding force
Standard design for disk size is for 100m length in a roll of the max pipe diameter
Double disk with servo motor
Suitabel for pipe 16-75mm
Servo motor for high speed and constant winding force
Touch screen and PLC control
Design of disk size can be client tailored by their packing size
Double disk corrugated pipe
Frequency inverter control for soft winding force to protect the corrugated pipe shape
Manual pipe discharging for keeping a small inner diameter of the final pipe roll
Winding disk size can be small
110mm pipe Double disk
For pipe 50-110mm
Torque motor for low speed and constant winding force.
Standard design for disk size is for 100m length in a roll of the max pipe diameter
180mm pipe single disk
For pipe 63-180mm
Torque motor for low speed and constant winding force.
Standard design for disk size is for 100m length in a roll of the max pipe diameter
Soft water proof profile coiler
Coiler for soft window proof
torque motor driven
Soft pipe coiler
Double disk coiler for soft pipe
Tailored Solution
Motor
Pipe diameter
Number of disk
Torque/Servo motor
16-210
Single/Double
Samples & Application
Heavy-Duty Coiler
Mark for width and inside diameter for finished pipe roll
